Jinpin KG4218-ZG AI/Deep Learning Server
The Jinpin KG4218-ZG is an AI server developed based on the third generation Intel® Xeon® Scalable Processor. It can support up to 10 NVIDIA GPU acceleration cards, dual Intel® Scalable processors, 8TB DDR4 ECC RDIMM/LRDIMM memory, and is designed for rack-mounted installation. The server adopts an independent air duct design to ensure heat dissipation and reduce system noise, making it suitable for applications such as AI, deep learning training, video decoding, and big data analysis.
Leading architecture
The server adopts an independent GPU compartment design, with a separate GPU cooling air duct to ensure stable GPU operation.
Supports NVIDIA NVLINK interconnect technology, which can increase memory and performance expansion.
Supports the new 100Gb network card, which improves data transfer efficiency.
Excellent performance
The server is equipped with two third-generation Intel® Xeon® Scalable processors, with a TDP of 270W.
The server has 32 DDR4 ECC RDIMM/LRDIMM memory slots, supporting up to 8TB of memory.
The server can support up to 10 NVIDIA Tesla computing cards.
Flexible configuration
The server supports 30 hard drives in the front, including 24 2.5-inch hot-swappable hard drives and 6 3.5-inch hard drives, and also supports 8 2.5-inch NVME U.2 hard drives.
Configured with 4 redundant power modules (single power module 2000W), with a power conversion efficiency of ≥94%.
Ready to use
The server comes pre-installed with Ubuntu operating system and deep learning SDK.
Deep learning frameworks include TensorFlow, PyTorch, etc.
The server is delivered in container form, which shortens the software deployment cycle and enables users to start using it right away, improving work efficiency.
|
Component |
Description |
|
Specification |
4U rackmount server |
|
Processor |
Supports 2 x 3rd Gen Intel® Xeon® Scalable processors (4300/5300/6300/8300 series) with a TDP of 270W. |
|
Memory |
Supports 32 memory slots with a maximum capacity of 8TB. Supports advanced memory error correction, memory mirroring, and other advanced features. |
|
Storage |
Supports 24 x 2.5-inch SAS/SATA hard drives and 6 x 3.5-inch hard drives. Supports 4 x M.2 NVMe SSDs and 2 x M.2 SATA SSDs with RAID1 support. Supports hot-swappable drives without opening the chassis. Equipped with 3 x 18TB 3.5-inch enterprise-class hard drives and 1 x 3.84TB 2.5-inch enterprise-class SSD. Supports one-key destruction function (soft and hard destruction) to ensure data security. |
|
Storage Controller |
RAID controller and SAS controller with support for RAID 0, 1, 5, and 10. |
|
Network Interface |
2 x RJ45 Gigabit Ethernet interfaces. |
|
Management |
1 x RJ45 interface for dedicated IPMI remote management. |
|
PCIe Expansion Slots |
12 x PCIe 4.0 x16 slots. |
|
I/O Interface |
2 x USB 3.0, 1 x VGA interface, 2 x RJ45, 1 x remote management port. |
|
Power Supply |
4 x 2000W platinum-level redundant power supplies with a power conversion efficiency of 94%. |
|
Operating System |
Windows，ubuntu ，Centos，SUSE、VMware |
|
Operating Environment |
Temperature: Operating: 10°C to 35°C; Non-operating: -40°C to 70°C. Humidity: Operating: 8% to 90%; Non-operating: 5% to 95% (non-condensing). |
